CHHorizontal Ice Cube Freezer

CH Horizontal Ice Freezers ideal for ice storing. Horizontal freezers ideal for ice cubes with a folding lid for multiple commercial and professional uses. Screen printing, decoration and personalized advertising!

With quality materials, sophisticated colors and the attention given to the smallest details, this equipment is one of the most sought after solutions by Gas Stations to supply ice to the public.

PERFECTION IN STORED ICECommercial use

CUSTOMIZATIONS

WIND FROST SYSTEM

WHITE INTERIOR

HANDLE

DIGITAL PRINTING

DRAIN

STAINLESS STEEL COVER

LOCK

SPECIFICATIONS

GENERAL CHARACTERISTICS

Energy Efficiency Class (Reg.2015/1904)F

Energy consumption (kWh/24h) 0,520

Energy consumption (kWh/year)211

Total Net Volume (It):102

Total Gross Volume (lt)102

Climate Class (EN16825)5

Temperature Class (EN16825)L1 (-18°C)

Operating Temperature-17ºC / -25ºC

Voltage (V)  220-240

Frequency (Hz)  50

Electric Power (W) 65

Rated Current (A)  0,47

Refrigerant Gas    R600a

Temperature Rise Time (h)  31

Freezing Capacity (Kg/24h) 11

DIMENSIONS

Dimensions without Packaging (mm)  850x550x650

Dimensions with Packaging (mm)  890x590x660

Weight without Packaging (kg)  24

Weight with Packaging (kg)  26

LOADING CAPACITY

Capacity 20´88

Capacity 40´187

Capacity 40´ High Cube216

Capacity Mega Truck240

Energy Efficiency Class (Reg.2015/1904)F

Energy consumption (kWh/24h) 0,620

Energy consumption (kWh/year)251

Total Net Volume (It):209

Total Gross Volume (lt)211

Climate Class (EN16825)5

Temperature Class (EN16825)L1 (-18°C)

Operating Temperature-17ºC / -25ºC

Voltage (V)  220-240

Frequency (Hz)  50

Electric Power (W) 81

Rated Current (A)  0,52

Refrigerant Gas    R600a

Temperature Rise Time (h)  37

Freezing Capacity (Kg/24h) 16,5

DIMENSIONS

Dimensions without Packaging (mm)  860x890x690

Dimensions with Packaging (mm)  880x950x710

Weight without Packaging (kg)  37

Weight with Packaging (kg)  39

LOADING CAPACITY

Capacity 20´42

Capacity 40´72

Capacity 40´ High Cube112

Capacity Mega Truck138

Energy Efficiency Class (Reg.2015/1904)F

Energy consumption (kWh/24h) 0,690

Energy consumption (kWh/year)280

Total Net Volume (It):275

Total Gross Volume (lt)278

Climate Class (EN16825)5

Temperature Class (EN16825)L1 (-18°C)

Operating Temperature-17ºC / -25ºC

Voltage (V)  220-240

Frequency (Hz)  50

Electric Power (W) 91

Rated Current (A)  0,57

Refrigerant Gas    R600a

Temperature Rise Time (h)  37

Freezing Capacity (Kg/24h) 24

DIMENSIONS

Dimensions without Packaging (mm)  860x1090x690

Dimensions with Packaging (mm)  880x1140x710

Weight without Packaging (kg)  44

Weight with Packaging (kg)  47

LOADING CAPACITY

Capacity 20´40

Capacity 40´66

Capacity 40´ High Cube96

Capacity Mega Truck111

Energy Efficiency Class (Reg.2015/1904)F

Energy consumption (kWh/24h) 0,760

Energy consumption (kWh/year)308

Total Net Volume (It):349

Total Gross Volume (lt)352

Climate Class (EN16825)5

Temperature Class (EN16825)L1 (-18°C)

Operating Temperature-17ºC / -25ºC

Voltage (V)  220-240

Frequency (Hz)  50

Electric Power (W) 101

Rated Current (A)  0,62

Refrigerant Gas    R600a

Temperature Rise Time (h)  37

Freezing Capacity (Kg/24h) 23

DIMENSIONS

Dimensions without Packaging (mm)  860x1320x690

Dimensions with Packaging (mm)  880x1370x710

Weight without Packaging (kg)  48

Weight with Packaging (kg)  51

LOADING CAPACITY

Capacity 20´28

Capacity 40´50

Capacity 40´ High Cube75

Capacity Mega Truck84

Energy Efficiency Class (Reg.2015/1904)F

Energy consumption (kWh/24h) 0,820

Energy consumption (kWh/year)333

Total Net Volume (It):411

Total Gross Volume (lt)414

Climate Class (EN16825)5

Temperature Class (EN16825)L1 (-18°C)

Operating Temperature-17ºC / -25ºC

Voltage (V)  220-240

Frequency (Hz)  50

Electric Power (W) 126

Rated Current (A)  0,72

Refrigerant Gas    R600a

Temperature Rise Time (h)  45

Freezing Capacity (Kg/24h) 24

DIMENSIONS

Dimensions without Packaging (mm)  860x1510x690

Dimensions with Packaging (mm)  880x1560x710

Weight without Packaging (kg)  53

Weight with Packaging (kg)  57

LOADING CAPACITY

Capacity 20´25

Capacity 40´46

Capacity 40´ High Cube69

Capacity Mega Truck81

Energy Efficiency Class (Reg.2015/1904)F

Energy consumption (kWh/24h) 0,879

Energy consumption (kWh/year)356

Total Net Volume (It):472

Total Gross Volume (lt)476

Climate Class (EN16825)5

Temperature Class (EN16825)L1 (-18°C)

Operating Temperature-17ºC / -25ºC

Voltage (V)  220-240

Frequency (Hz)  50

Electric Power (W) 210

Rated Current (A)  0,8

Refrigerant Gas    R600a

Temperature Rise Time (h)  45

Freezing Capacity (Kg/24h) 24

DIMENSIONS

Dimensions without Packaging (mm)  860x1700x690

Dimensions with Packaging (mm)  880x1750x710

Weight without Packaging (kg)  58

Weight with Packaging (kg)  63

LOADING CAPACITY

Capacity 20´18

Capacity 40´38

Capacity 40´ High Cube60

Capacity Mega Truck78
