ICE TVSIce Cream Saver with Flat Glass Lid

The ICE TVS ice cream saver will store your ice cream effectively and with great efficiency. The technology used in the internal ventilated condenser allows for a greater flow of air inside the equipment, maintaining more uniform temperatures and guaranteeing a high freezing capacity, making your ice creams always perfect!

ICE TVS is equipped with an electronic controller that allows you to control multiple parameters, making your chest suitable for every moment. This chest is a model of easy maintenance and easy cleaning, ensuring greater efficiency of your equipment.

We have a range of models in different sizes, capacities and OEM customization | PRIVATE LABEL.

Different sizes, same performance.Optimize equipment use and profitability.

CUSTOMIZATIONS

GLASS OR SOLID LIDS

LED LIGHTING

BASKETS

LOCK

DRAIN

DIGITAL PRINTING

COLOR

SPECIFICATIONS

GENERAL CHARACTERISTICS

Energy class (Reg.2019/2018)D

Energy consumption (kWh/24h) 1,95

Energy consumption (kWh/year)712

Total Net Volume (l)185

Total Gross Volume (l)222

Climate Class (ISO 22043;ISO 23953-2)C;5

Temperature Class (ISO 22043)C1 (-18°C)

Operating Temperature-22°C / -9°C

Voltage (V)  220-240

Frequency (Hz)  50

Power (W)  115

Rated Current (A)  0,90

Refrigerant Gas    R600a

Temperature Rise Time (h)  12

Sliding door Yes

Lid with lockYes

Electronic control Yes

Alarm Yes

CastorsYes

Frontal defrost drain Yes

DIMENSIONS

Dimensions without Packaging (mm)  895x843x670

Dimensions with Packaging (mm)  922x900x730

Weight without Packaging (kg)  48

Weight with Packaging (kg)  52

LOADING CAPACITY

Capacity 20´36

Capacity 40´78

Capacity 40´ High Cube117

Capacity Mega Truck144

Energy class (Reg.2019/2018)D

Energy consumption (kWh/24h) 2,34

Energy consumption (kWh/year)854

Total Net Volume (l)256

Total Gross Volume (l)304

Climate Class (ISO 22043;ISO 23953-2)C;5

Temperature Class (ISO 22043)C1 (-18°C)

Operating Temperature-22°C / -9°C

Voltage (V)  220-240

Frequency (Hz)  50

Power (W)  135

Rated Current (A)  1,00

Refrigerant Gas    R600a

Temperature Rise Time (h)  13

Sliding door Yes

Lid with lockYes

Electronic control Yes

Alarm Yes

CastorsYes

Frontal defrost drain Yes

DIMENSIONS

Dimensions without Packaging (mm)  895x1063x670

Dimensions with Packaging (mm)  922x1120x730

Weight without Packaging (kg)  54

Weight with Packaging (kg)  59

LOADING CAPACITY

Capacity 20´32

Capacity 40´64

Capacity 40´ High Cube90

Capacity Mega Truck108

Energy class (Reg.2019/2018)D

Energy consumption (kWh/24h) 2,72

Energy consumption (kWh/year)993

Total Net Volume (l)327

Total Gross Volume (l)387

Climate Class (ISO 22043;ISO 23953-2)C;5

Temperature Class (ISO 22043)C1 (-18°C)

Operating Temperature-22°C / -9°C

Voltage (V)  220-240

Frequency (Hz)  50

Power (W)  190

Rated Current (A)  1,80

Refrigerant Gas    R600a

Temperature Rise Time (h)  12

Sliding door Yes

Lid with lockYes

Electronic control Yes

Alarm Yes

CastorsYes

Frontal defrost drain Yes

DIMENSIONS

Dimensions without Packaging (mm)  895x1063x670

Dimensions with Packaging (mm)  922x1120x730

Weight without Packaging (kg)  54

Weight with Packaging (kg)  59

LOADING CAPACITY

Capacity 20´32

Capacity 40´64

Capacity 40´ High Cube90

Capacity Mega Truck108

Energy class (Reg.2019/2018)D

Energy consumption (kWh/24h) 3,1

Energy consumption (kWh/year)1132

Total Net Volume (l)398

Total Gross Volume (l)470

Climate Class (ISO 22043;ISO 23953-2)C;5

Temperature Class (ISO 22043)C1 (-18°C)

Operating Temperature-22°C / -9°C

Voltage (V)  220-240

Frequency (Hz)  50

Power (W)  190

Rated Current (A)  1,80

Refrigerant Gas    R600a

Temperature Rise Time (h)  11

Sliding door Yes

Lid with lockYes

Electronic control Yes

Alarm Yes

CastorsYes

Frontal defrost drain Yes

DIMENSIONS

Dimensions without Packaging (mm)  895x1503x670

Dimensions with Packaging (mm)  922x1560x730

Weight without Packaging (kg)  60

Weight with Packaging (kg)  67

LOADING CAPACITY

Capacity 20´20

Capacity 40´44

Capacity 40´ High Cube59

Capacity Mega Truck75
